Strip, Wire & Bar Machines
Wheelabrator’s Strip, Wire &Bar Machines are purpose-built shot blast systems for the inline processing of long, continuous materials such as steel strip,wire coil, bar stock, and rod.Designed for high-speed,high-volume environments,these machines deliver precise, uniform surface treatment while integrating seamlessly into rolling,drawing, coating, or finishing lines.
With tailored blast wheel configurations and adaptable inlet/outlet sealing systems,the range ensures effective descaling, cleaning, and preparation of metallic products without interrupting continuous production flow.
Strip, Wire & Bar Machines
Applications
Removal of mill scale and rust from:
- Hot-rolled and cold-rolled steel strip
- Wire coils and rods
- Rebars and steel bar stock
- Surface preparation before:
- Drawing, galvanising, coating, or straightening
- Welding or mechanical forming
Cleaning after:
- Heat treatment or rolling processes
Key Features
Inline Operation
Processes material continuously at speeds up to 120 m/min
Multi-Wheel Layouts
Precise blast coverage from all sides-top, bottom, and lateral
Sealed Pass-Through Design
Special inlet/outlet seals prevent abrasive leakage and protect line integrity
Wear-Resistant Construction
Manganese steel linings and reinforced components extend service life
Custom Integration
Adaptable to specific layout requirements and automation levels
Clean Operation
Integrated abrasive recycling and ATEX-compliant dust extraction systems
Configuration / Options
Product Formats
- Wire (single or multi-strand)
- Strip (thin or wide coil)
- Bar and rod (various cross-sections)
Blast Wheel Arrangement
- 4 to 8 wheels positioned for full surface exposure
- Power per wheel: 11–22 kW
Process Speed
Up to 120 m/min depending on material and cleaning level
Abrasive Recovery System
Magnetic separator, airwash cleaner, and vibratory sieve
